Viva Series, Antenna Heights 293
13.3.3 Pole Setup
)
• One of the Leica standard antennas is used, for example GS15. All former Leica antenna
types are supported.
• Leica standard accessories are used.
Pole setup
a) Mechanical reference plane
b) Vertical phase centre offset for L1
c) Vertical phase centre offset for L2
d) Vertical height reading, 2.00 m for the fully
extended Leica telescopic pole.
Vertical offset = 0
GS_035
d
b
c
a
