Viva Series, Antenna Heights 294
Vertical height reading The vertical height reading is the height difference between the bottom end and the top end
of the pole. Usually, this height difference is a fixed value.
Next step • At the beginning of a survey, enter the vertical height reading into the instrument. A
standard rover configuration with a standard antenna setup record for a pole setup uses
the value of 2.00 m already as default.
• The vertical offset of 0.00 m is stored in the antenna setup record for a pole setup and
will automatically be taken into account. It does not need to be entered.
•Refer to Overview for the vertical phase centre variations.
)
For other than the Leica standard poles, the dimensions must be determined.
)
For other than Leica standard antennas, the vertical offset must be measured. It must be
entered in the antenna setup record.
