Viva Series, COGO 852

38.9 COGO Calculation - Shift, Rotate & Scale

38.9.1 Selecting the Shift, Rotate & Scale Method and the Points to be Moved

Access Select Main Menu: Go to Work!\COGO\Shift, rotate & scale.

COGO Shift, Rotate &

Scale

Key Description

OK To select a method and to continue with the subsequent screen.

Default Chapter5
