Viva Series, Instrument connections - All other connections 379
18.9 NMEA 1 / NMEA 2
)
Unavailable for GS05/GS06/GS08/GS12.
)
For GS05/GS06/GS08/GS12, streaming of GGA messages is supported for RTK network oper-
ations.
Description National Marine Electronics Association has developed a message standard related to the
marine electronics industry. NMEA messages have been accepted as the standard for
sharing specific data information between companies since the late 1970s. Refer to
"Appendix F NMEA Message Formats" for a comprehensive description of each NMEA
message.
The settings on this screen define the port, the device and the type of NMEA message to be
used for the NMEA Out connection.
Up to two NMEA Out connections can be configured. Each NMEA Out connection can output
different messages at different rates with different talker IDs. The output of NMEA
messages on both ports is simultaneous.
The screens for the configuration of both NMEA connections are identical except for the title
- NMEA Output 1 and NMEA Output 2. For simplicity, the title NMEA Output 1 is used in the
following.
Access For RTK rover:
•In Connection Settings, GS connections page, highlight NMEA 1 or NMEA 2. Edit...
To Next Page
