Viva Series, Determine Coordinate System 906

39.3.3 Modifying a Coordinate System

Access OK in Determine Coord System when Method: Modify existing.

Coordinate Systems Select an existing coordinate system and press OK.

All the following steps are identical with the determination of a new coordinate system from

the Matched Points (n) screen onwards. Refer to "39.3.2 Determining a New Coordinate

System"
