Viva Series, Antenna Heights 282
13 Antenna Heights
13.1 Overview
Description The height of the GNSS antenna above a point consists of three components:
• the vertical or slope height reading,
• the vertical offset,
• the vertical phase centre variations.
For most operations, pre-configured standard settings in the instrument can be used. They
automatically take the vertical phase centre variations into account.
Vertical or slope height Only vertical antenna heights measured to the Mechanical Reference Plane are accepted.
Measurements
required
This table is an overview of required measurements depending on antennas, setup and
accessories. All former Leica antenna types are supported.
IF the antenna is AND the accesso-
ries are
AND the setup is THEN the measure-
ments required are
Leica antenna, for
example GS15
standard Leica tripod vertical height from
height hook
Leica antenna, for
example GS15
standard Leica pole none.
Value is 2.00 m.
Leica antenna, for
example GS15
standard Leica pillar vertical height to the
MRP.
Leica antenna, for
example GS15
non-Leica any • vertical height to
the MRP.
