Assembly 1: Covers
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X7678 1 1 Rear door See “Rear door removal”
on page 285.
2 40X7726 1 1 Rear door support N/A
3 40X7671 1 1 Rear lower cover (integrated 550‑sheet tray) See “Rear lower cover
removal” on page 280.
3 40X8404 1 1 Rear lower cover (integrated 250‑sheet tray) See “Rear lower cover
removal” on page 280.
4 40X7680 1 1 Right cover (integrated 550‑sheet tray) See “Right cover
removal” on page 283.
4 40X8403 1 1 Right cover (integrated 250‑sheet tray) See “Right cover
removal” on page 283.
5 40X7670 1 1 Right inner cover See “Right inner cover
removal” on page 309.
6 40X7690 2 1 Torsion spring N/A
7 40X7715 2 1 Front door support link N/A
8 40X7725 1 1 MPF tray See “MPF tray removal”
on page 308.
9 40X7674 1 1 Front door See “Front door
removal” on page 288.
10 40X7669 1 1 Inner left cover See “Left inner cover
removal” on page 295.
11 40X7672 1 1 Controller board access cover See “Controller board
access cover removal”
on page 350.
12 40X7679 1 1 Left cover (integrated 550‑sheet tray) See “Left cover removal”
on page 277.
12 40X8402 1 1 Left cover (integrated 250‑sheet tray) See “Left cover removal”
on page 277.
13 40X7677 1 1 Bin sensor cover See “Output bin sensor
cover removal” on
page 326.
14 40X7675 1 1 Standard bin cover (integrated 550‑sheet tray) See “Standard bin cover
removal” on page 330.
14 40X8397 1 1 Standard bin cover (integrated 250‑sheet tray) See “Standard bin cover
removal” on page 330.
15 40X8398 1 1 Fuser wiper cover (hot roll fuser printer only) N/A
16 40X7604 2 1 Output bin guide N/A
17 40X7673 1 1 Top cover See “Top cover removal”
on page 282.
4063
Parts catalog
544
