Asm-index P/N Units/mach Units/FRU Description
Removal
procedure
13 40X7572 1 1 Controller board (7” tilting display printers only) See “Controller
board removal” on
page 349.
14 40X7722 1 1 Controller board access shield See “Controller
board access shield
removal” on
page 351.
15 40X7692 1 1 Toner cartridge smart chip contact with cable See “Laser
printhead
removal” on
page 291.
16 40X8034 1 1 Option card cover plate N/A
17 40X7691 1 1 Sensor (standard bin full) with output bin guide See “Sensor
(standard bin full)
removal” on
page 329.
18 40X7689 1 1 Imaging unit smart chip contact with cable See “Laser
printhead
removal” on
page 291.
19 40X7707 1 1 Printhead power cable See “Laser
printhead
removal” on
page 291.
20 40X7708 1 1 Printhead video cable See “Laser
printhead
removal” on
page 291.
21 40X7597 1 1 Laser printhead (quad diode) (belt fuser printers only)
Includes data and power cables
See “Laser
printhead
removal” on
page 291.
21 40X8481 1 1 Laser printhead (dual diode) (hot roller fuser printers
only)
Includes data and power cables
See “Laser
printhead
removal” on
page 291.
22 40X7592 1 1 Interrupt sensor
• sensor (rear door interlock)
See “Sensor (rear
door interlock)
removal” on
page 328.
4063
Parts catalog
551
