Assembly 16: Output expander option
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8186 1 1 Output expander rear door “Output expander rear door removal”
on page 447
2 40X8196 1 1 Output expander top cover “Output expander top cover removal”
on page 446
3 40X8187 1 1 Output expander right cover “Output expander right cover
removal” on page 450
4 40X8191 1 1 Sensor (media bin full) with flag “Sensor (media bin full) with flag
removal” on page 449
5 40X8206 1 1 Upper interface cable “Upper interface cable removal” on
page 456
6 40X8205 1 1 Lower interface cable “Lower interface cable removal” on
page 455
7 40X8199 1 1 Output expander controller PCBA “Output expander controller PCBA
removal” on page 454
8 40X8190 1 1 Output expander left cover “Output expander left cover removal”
on page 452
9 40X8192 1 1 Spring with string “Spring with string removal” on
page 458
NS 40X8500 1 1 Actuator flag (media bin full) N/A
4063
Parts catalog
578
