Assembly 17: High capacity output expander option
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8197 1 1 HCOE rear door “HCOE rear door removal” on
page 461
2 40X8196 1 1 HCOE top cover “HCOE top cover removal” on
page 460
3 40X8198 1 1 HCOE right cover “HCOE right outer cover
removal” on page 463
4 40X8191 1 1 Sensor (HCOE media bin full) with flag “Sensor (HCOE media bin full)
with flag removal” on page 463
5 40X8205 1 1 HCOE lower interface cable “HCOE lower interface cable
removal” on page 469
6 40X8206 1 1 HCOE upper interface cable “HCOE upper interface cable
removal” on page 470
7 40X8199 1 1 HCOE controller PCBA “HCOE controller PCBA removal”
on page 467
8 40X8202 1 1 HCOE left cover “HCOE left cover removal” on
page 465
NS 40X8500 1 1 Actuator flag (media bin full) N/A
4063
Parts catalog
580
