Assembly 19: Staple finisher option 2
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8212 1 1 Tamper drive belt “Tamper drive belt removal” on
page 492
2 40X8209 1 1 Media stack flap (right) “Media stack flap (right) removal”
on page 485
3 40X8217 1 1 Sensor (bin full send) “Sensor (bin full send) removal” on
page 497
4 40X8223 1 1 Stapler carriage assembly “Stapler carriage assembly
removal” on page 479
5 40X8225 1 1 Stapler door close limit switch “Stapler door close limit switch
removal” on page 476
6 40X7592 1 1 Sensor (cartridge door interlock) “Sensor (cartridge door interlock)
removal” on page 476
7 40X8216 1 1 Stapler right cover “Stapler right cover removal” on
page 474
8 40X8215 1 1 Stapler cartridge access door “Stapler cartridge access door
removal” on page 482
9 40X8226 1 1 Stapler spring with string “Stapler spring with string removal”
on page 484
10 40X8218 1 1 Standard output bin LED “Standard output bin LED removal”
on page 489
11 40X8219 1 1 Sensor (finisher bin media present) “Sensor (finisher bin media present)
removal” on page 490
12 40X8211 1 1 Tamper motor (left) “Tamper motor (left) removal” on
page 491
13 40X8211 1 1 Tamper motor (right) “Tamper motor (right) removal” on
page 491
14 40X8210 1 1 Media stack flap (left) “Media stack flap (left) removal” on
page 486
4063
Parts catalog
584
