Assembly 20: Mailbox option 1
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8248 4 4 Sensor (bin full receive) “Sensor (mailbox bin full receive)
removal” on page 515
2 40X8247 4 4 Mailbox media bin full flag “Mailbox media bin full flag removal” on
page 514
3 40X8244 1 1 Mailbox controller PCBA “Mailbox controller PCBA removal” on
page 507
4 40X8246 1 1 Mailbox left cover “Mailbox left cover removal” on page
506
5 40X8256 1 1 Mailbox divert motor “Mailbox divert motor removal” on
page 512
6 40X8253 1 1 Mailbox lower interface cable “Mailbox lower interface cable removal”
on page 510
7 40X7592 1 1 Mailbox sensor (divert motor) “Sensor (mailbox divert motor) removal”
on page 509
8 40X8252 1 1 Mailbox spring with string “Mailbox spring with string removal” on
page 503
9 40X8254 1 1 Mailbox upper interface cable “Mailbox upper interface cable removal”
on page 512
10 40X8242 1 1 Mailbox rear door “Mailbox rear door removal” on page
500
4063
