RS-485 Communication Features

5.2.8 Parameter Group for Data Transmission

By defining a parameter group for data transmission, the communication addresses registered in

the communication function group (COM) can be used in communication. Parameter group for

data transmission may be defined to transmit multiple parameters at once, into the

communication frame.

Group

Code

Name

LCD Display

Parameter Setting

Setting range

Unit

COM

31-38

Output communication

address x

Para Status-x - - 0000-FFFF Hex

51-58

Input communication

address x

Para Control-x - - 0000-FFFF Hex

Currently Registered CM Group Parameter

Address Parameter Assigned content by bit

0h0100-0h0107

Status Parameter-1-

Status Parameter-8

Parameter communication code value registered at COM-31-

38 (Read-only)

0h0110-0h0117

Control Parameter-1-

Control Parameter-8

Parameter communication code value registered at COM-51-

58 (Read/Write access)

Note

When registering control parameters, register the operation speed (0h0005, 0h0380, 0h0381) and

operation command (0h0006, 0h0382) parameters at the end of a parameter control frame. For

example, when the parameter control frame has 5 parameter control items (Para Control - x), register

the operation speed at Para Control-4 and the operation command to Para Control-5.
