LSIS S100 User Manual

99
Learning Basic Features
4.13.3 User V/F Pattern Operation
The S100 inverter allows the configuration of user-defined V/F patterns to suit the load
characteristics of special motors.
Group
Code
Name
LCD Display
Parameter Setting
Setting Range
Unit
BAS
07 V/F pattern V/F Pattern 2 User V/F
0–3
-
41 User Frequency1 User Freq 1 15.00
0–
Maximum
frequency
Hz
42
User Voltage1
User Volt 1
25
0–100
%
43 User Frequency2 User Freq 2 30.00
0–
Maximum
frequency
Hz
44
User Voltage2
User Volt 2
50
0–100
%
45 User Frequency3 User Freq 3 45.00
0–
Maximum
frequency
Hz
46
User Voltage3
User Volt 3
75
0–100
%
47 User Frequency4 User Freq 4
Maximum
frequency
0–
Maximum
frequency
Hz
48
User Voltage4
User Volt 4
100
0–100%
%
