Learning Basic Features
4.24 Fire Mode Operation
This function is used to allow the inverter to ignore minor faults during emergency situations, such
as fire, and provides continuous operation to fire pumps.
When turned on, Fire mode forces the inverter to ignore all minor fault trips and repeat a Reset
and Restart for major fault trips, regardless of the restart trial count limit. The retry delay time set at
PRT-10 (Retry Delay) still applies while the inverter performs a Reset and Restart.
Fire Mode Parameter Settings
Group
Code
Name
LCD Display
Parameter Setting
Setting Range
Unit
ADV
80
Fire Mode selection
Fire Mode Sel
1
Fire Mode
0–2
-
81 Fire Mode frequency
Fire Mode
Freq
0-60 0–60
82
Fire Mode run direction
Fire Mode Dir
0–1
0–1
83
Fire Mode operation
count
Fire Mode
Cnt
Not configurable - -
IN
65–
71
Px terminal configuration
Px Define
(Px: P1– P7)
51 Fire Mode 0–54 -
The inverter runs in Fire mode when ADV-80 (Fire Mode Sel) is set to ‘2 (Fire Mode)’, and the multi-
function terminal (IN-65–71) configured for Fire mode (51: Fire Mode) is turned on. The Fire mode
count increases by 1 at ADV-83 (Fire Mode Count) each time a Fire mode operation is run.
Fire mode operation may result in inverter malfunction. Note that Fire mode operation voids the
product warranty – the inverter is covered by the product warranty only when the Fire mode count is
‘0.’
