LSIS S100 User Manual

114
Learning Basic Features
P2P Setting Details
Code
Description
COM-95 Int 485 Func
Set master inverter to 1(P2P Master), slave inverter to 2(P2P Slave).
USS-80–82 P2P Input Data
Input data sent from the slave inverter.
USS-85, 88 P2P Output Data
Output data transmitted to the slave inverter.
• P2P features work only with code version 1.00, IO S/W version 0.11, and keypad S/W version 1.07 or
higher versions.
•
Set the user sequence functions to use P2P features.
4.22 Multi-keypad Setting
Use multi-keypad settings to control more than one inverter with one keypad. To use this function,
first configure RS-485 communication.
The group of inverters to be controlled by the keypad will include a master inverter. The master
inverter monitors the other inverters, and slave inverter responds to the master inverter’s input.
When using multi-function output, a slave inverter can select to use either the master inverter’s
output or its own output. When using the multi keypad, first designate the slave inverter and then
the master inverter. If the master inverter is designated first, connected inverters may interpret the
condition as a loss of communication.
Master Parameter
Group
Code
Name
LCD Display
Parameter Setting
Setting Range
Unit
COM 95
P2P Communication
selection
Int 485 Func 3 KPD-Ready
0–3
-
CNF
03 Multi-keypad ID Multi KPD ID 3
3–99
-
42 Multi-function key selection Multi Key Sel 4 Multi KPD
0–4
-
Slave Parameter
Group
Code
Name
LCD Display
Parameter Setting
Setting Range
Unit
COM
01 Station ID Int485 St ID 3
3–99
-
95 P2P communication options Int 485 Func 3 KPD-Ready
0–3
-
