Learning Basic Features
4.5 Command Source Configuration
Various devices can be selected as command input devices for theS100 inverter. Input devices
available to select include keypad, multi-function input terminal, RS-485 communication and field
bus adapter. If UserSeqLink is selected, the common area can be linked with user sequence output
and can be used as command.
Group
Code
Name
LCD Display
Parameter Setting
Setting Range
Unit
DRV 06 Command Source Cmd Source*
0
Keypad
0–5
-
1
Fx/Rx-1
2
Fx/Rx-2
3
Int 485
4
Field Bus
5
UserSeqLink
4.5.1 The Keypad as a Command Input Device
The keypad can be selected as a command input device to send command signals to the inverter.
This is configured by setting the drv (command source) code to 0 (Keypad). Press the [RUN] key on
the keypad to start an operation, and the [STOP/RESET] key to end it.
group
Code
Name
LCD Display
Parameter Setting
Setting Range
Unit
DRV 06 Command source Cmd Source* 0 KeyPad
0–4
-
4.5.2 Terminal Block as a Command Input Device (Fwd/Rev Run
Commands)
Multi-function terminals can be selected as a command input device. This is configured by setting
the 06 (command source) code in the DRV group to 1(Fx/Rx). Select 2 terminals for the forward
and reverse operations, and then set the relevant codes (2 of the 7 multi-function terminal codes,
IN-65–71 for P1–P7) to 1(Fx) and 2(Rx) respectively. This application enables both terminals to be
turned on or off at the same time, constituting a stop command that will cause the inverter to stop
operation.
Group
Code
Name
LCD Display
Parameter Setting
Setting Range
Unit
DRV 06
Command source
Cmd Source*
1
Fx/Rx-1
0–5
-
IN
65–71
Px terminal
configuration
Px Define(Px: P1–
P7)
1
Fx
0–54
-
2
Rx
