LSIS S100 User Manual

151
RS-485 Communication Features
5.5.2 Control Area Parameter (Read/ Write)
Comm. Address Parameter Scale Unit Assigned Content by Bit
0h0380
Frequency
command
0.01 Hz Command frequency setting
0h0381
RPM command
1
rpm
Command rpm setting
0h0382
Operation
command
- -
B7
Reserved
B6
Reserved
B5
Reserved
B4
Reserved
B3
0  1: Free-run stop
B2
0  1: Trip initialization
B1
0: Reverse command, 1: Forward
command
B0
0: Stop command, 1: Run command
Example: Forward operation command 0003h,
Reverse operation command 0001h.
0h0383
Acceleration
time
0.1 s Acceleration time setting
0h0384
Deceleration
time
0.1 s Deceleration time setting
0h0385
Virtual digital
input control (0:
Off, 1:On)
- -
BI5
Reserved
-
Reserved
B8
Reserved
B7
Virtual DI 8(COM-77)
B6
Virtual DI 7(COM-76)
B5
Virtual DI 6(COM-75)
B4
Virtual DI 5(COM-74)
B3
Virtual DI 4(COM-73)
B2
Virtual DI 3(COM-72)
B1
Virtual DI 2(COM-71)
B0
Virtual DI 1(COM-70)
0h0386
Digital output
control
(0:Off, 1:On)
- -
BI5
Reserved
BI4
Reserved
BI3
Reserved
BI2
Reserved
BI1
Reserved
BI0
Reserved
B9
Reserved
B8
Reserved
B7
Reserved
B6
Reserved
B5
Reserved
