LSIS S100 User Manual

260
Technical Specification
9.8 Continuous Rated Current Derating
Derating by Carrier Frequency
The continuous rated current of the inverter is limited based on the carrier frequency. Refer to the
following graph.
Item
Unit
30 kW
37 kW
45 kW
55 kW
75 kW
f
s, ND
[kHz]
2
f
s, c
6
4
f
s, max
10
7
% of DR
[%]
70
Derating by Input Voltage
The continuous rated current of the inverter is limited based on the input voltage. Refer to the
following graph.
