9 Technical Specification
9.1 Input and Output Specification
3-Phase 400 V (30–75 kW)
Model □□□□ S100–4 □□□
0300 0370 0450 0550 0750
Applied
motor
HP 40 50 60 75 100
kW
30
37
45
55
75
Rated
output
Rated capacity
[440Vac
Input](kVA)
Heavy load
46
57
69
84
116
Normal load 55 67 78 106 126
Rated current
[3-Phase
input] (A)
Heavy load
61
75
91
110
152
Normal load 75 91 107 142 169
Rated current
[Single-Phase
input] (A)
Heavy load
32 39 47 57 78
Normal load
39 47 55 73 87
Output frequency 0-400 Hz (IM Sensorless: 0-120 Hz)
Output voltage (V) 3-phase 380-480 V
Rated input
Working voltage (V)
3-phase 380-480 VAC (-15% to +10%)
Single phase 480VAC(-5% to +10%)
Input frequency
50-60 Hz (
±
5%)
(In case of single phase input, input frequency is only
60Hz(±5%).)
Rated current
(A)
Heavy load 56 69 85 103 143
Normal load
69
85
100
134
160
Weight (lb /kg)
(Non EMC Filter type)
57/26
(55/25)
77/35
(75/34)
77/35
(75/34)
95/43 95/43
*S100 inverters rated at 30 kW or more do not support I/O extensions or IP66 certification.
*The 55-75 kW inverters do not have built-in EMC since they satisfy EMC standards even without it.
