RS-485 Communication Features
5.2.6 Saving Parameters Defined by Communication
If you turn off the inverter after setting the common area parameters or keypad parameters via
communication and operate the inverter, the changes are lost and the values changed via
communication revert to the previous setting values when you turn on the inverter.
Set CNF-48 to 1 (Yes) to allow all the changes over comunication to be saved, so that the inverter
retains all the existing values even after the power has been turned off.
Setting address 0h03E0 to 0 and then setting it again to 1 via communication allows the existing
parameter settings to be saved. However, setting address 0h03E0 to 1 and then setting it to 0 does
not carry out the same function.
Group
Code
Name
LCD Display
Parameter Setting
Setting range
Unit
CNF 48 Save parameters Parameter Save
0
No
0 -1 -
1
Yes
5.2.7 Total Memory Map for Communication
Communication Area
Memory Map
Details
Communication common
compatible area
0h0000-0h00FF iS5, iP5A, iV5, iG5A compatible area
Parameter registration type
area
0h0100-0h01FF
Areas registered at COM-31–38 and COM-
51–58
0h0200-0h023F
Area registered for User Group
0h0240-0h027F
Area registered for Macro Group
0h0280-0h02FF
Reserved
S100 communication
common area
0h0300-0h037F
Inverter monitoring area
0h0380-0h03DF
Inverter control area
0h03E0-0h03FF
Inverter memory control area
0h0400-0h0FFF
Reserved
0h1100
DRV Group
0h1200
BAS Group
0h1300
ADV Group
0h1400
CON Group
0h1500
IN Group
0h1600
OUT Group
0h1700
COM Group
0h1800
APP Group
0h1B00
PRT Group
0h1C00
M2 Group
