LSIS S100 - 2 Nd Motor Function Group (PAR→M2)

202
Table of Functions
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property* V/F SL Ref.
95 0h1B5F Fault history 5 - - - O I/P
-
96 0h1B60
Fault history
deletion
-
0 No
0:No O I/P
-
1
Yes
6.10 2nd Motor Function group (PAR→M2)
The 2nd Motor function group will be displayed if any of IN-65-71 is set to 26 (2nd MOTOR). In the
following table, the data shaded in grey will be displayed when a related code has been selected.
SL: Sensorless vector control (DRV-09) , I – IM Sensorless, P – PM Sensorless
*O/X: Write-enabled during operation
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property* V/F SL Ref.
00
-
Jump Code
Jump Code
1-99
14
O
O
I
p.52
04 0h1C04
Acceleration
time
M2-Acc Time 0.0-600.0(s) 20.0 O O I -
05 0h1C05
Deceleration
time
M2-Dec
Time
0.0-600.0(s) 30.0 O O I -
06 0h1C06 Motor capacity M2-Capacity
0
0.2 kW
- X O I -
1
0.4 kW
2
0.75 kW
3
1.1 kW
4
1.5 kW
5
2.2 kW
6
3.0 kW
7
3.7 kW
8
4.0 kW
9
5.5 kW
10
7.5 kW
11
11.0 kW
12
15.0 kW
13
18.5 kW
14
22.0 kW
15
30.0 kW
16
37.0 kW
17
45.0 kW
18
55.0 kW
19
75.0 kW
20
90.0 kW
