LSIS S100 User Manual

Technical Specification
249
9.2 Product Specification Details
Items
Description
Control
Control method
V/F control, slip compensation, sensorless vector
Frequency settings
power resolution
Digital command: 0.01 Hz
Analog command: 0.06 Hz (60 Hz standard)
Frequency accuracy 1% of maximum output frequency
V/F pattern
Linear, square reduction, user V/F
Overload capacity
Heavy load rated current: 150% 1 min, normal load rated current:
120% 1 min
Torque boost Manual torque boost, automatic torque boost
Operation
Operation type
Select key pad, terminal strip, or communication operation
Frequency settings
Analog type: -10–10 V, 0–10 V, 4–20 mA
Digital type: key pad, pulse train input
Operation function
• PID control
• 3-wire operation
• Frequency limit
• Second function
• Anti-forward and reverse
direction rotation
• Commercial transition
• Speed search
• Power braking
•
Leakage reduction
• Up-down operation
• DC braking
• Frequency jump
• Slip compensation
• Automatic restart
• Automatic tuning
• Energy buffering
• Flux braking
• Fire Mode
Input
Multi
function
terminal
(7EA)
P1-P7
Select PNP (Source) or NPN (Sink) mode. Functions can be set
according to IN-65–IN-71 codes and parameter settings.
• Forward direction operation
• Reset
• Emergency stop
• Multi step speed frequency-
high/med/low
• DC braking during stop
• Frequency increase
• 3-wire
• Local/remote operation mode
transition
• Select acc/dec/stop
• Reverse direction
operation
• External trip
• Jog operation
• Multi step acc/dec-
high/med/low
• Second motor selection
• Frequency reduction
• Fix analog command
frequency
•
Transtion from PID to
general operation
Pulse train
0-32 kHz, Low Level: 0-2.5 V, High Level: 3.5-12 V
Output
Multi
function
open
Fault output and inverter
operation status output
Less than DC 24 V, 50 mA
