6.13 Groups for LCD Keypad Only

6.13.1 Trip Mode (TRP Last-x)

Code Name LCD Display Setting Range Initial Value Ref.

00 Trip type display Trip Name(x) - - -

01 Frequency reference at trip

Output Freq - - -

02 Output current at trip Output Current - - -

Acceleration/Deceleration

state at trip

Inverter State - - -

04 DC section state DCLink Voltage - - -

05 NTC temperature Temperature - - -

Input terminal state

DI State - 0000 0000 -

07 Output terminal state DO State - 000 -

08 Trip time after Power on Trip On Time - 0/00/00 00:00 -

Trip time after operation

start

Trip Run Time - 0/00/00 00:00 -

10 Delete trip history Trip Delete?

Yes

6.13.2 Config Mode (CNF)

Code Name LCD Display Setting Range Initial Value Ref.

00 Jump code Jump Code 1-99 42 p.52

Keypad language

selection

Language Sel

English

0 : English -

Russian

Spanish

Italian

Turkish

02 LCD constrast adjustment LCD Contrast - - -

03 Multi keypad ID Multi KPD ID 3-99 3 p.114

10 Inverter S/W version Inv S/W Ver - - -

11 LCD keypad S/W version Keypad S/W Ver - - -

12 LCD keypad title version KPD Title Ver - - -
