LSIS S100 User Manual

228
Table of Functions
Code Name LCD Display Setting Range Initial Value Ref.
20
Status window display
item
Anytime Para 0 Frequency
0: Frequency -
21
Monitor mode display
item1
Monitor Line-1 1 Speed
0: Frequency -
22
Monitor mode display
item2
Monitor Line-2 2 Output Current
2:Output
Current
-
23
Monitor mode display
item3
Monitor Line-3
3 Output Voltage
3:Output
Voltage
-
4 Output Power
5 WHour Counter
6 DCLink Voltage
7 DI State
8 DO State
9 V1 Monitor(V)
10 V1 Monitor(%)
13 V2 Monitor(V)
14 V2 Monitor(%)
15 I2 Monitor(mA)
16 I2 Monitor(%)
17 PID Output
18 PID Ref Value
19 PID Fdb Value
20 Torque
21 Torque Limit
23 Speed Limit
24 Load Speed
24
Monitor mode
initialization
Mon Mode Init
0 No
0:No -
1 Yes
30
Option slot 1 type display Option-1 Type 0 None
0:None -
31
Option slot 2 type display Option-2 Type 6 Ethernet
0:None
-
32
Option slot 3 type display Option-3 Type 9 CANopen
0:None
-
40
Parameter initialization Parameter Init
0 No
-
1 All Grp
2 DRV Grp
3 BAS Grp
4 ADV Grp
5
CON Grp
6 IN Grp
