Table of Functions
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property* V/F SL Ref.
30 0h1C1E
Electronic
thermal
continuous
rating
M2-ETH
Cont
50-150(%) 100 X O I -
40 0h1C28
Rotation count
speed gain
Load Spd
Gain
0~6000.0[%] 100.0 O O I -
41 0h1C29
Rotation count
speed scale
Load Spd
Scale
0
x 1
0: x 1 O O I -
1
x 0.1
2
x 0.01
3
x 0.001
4
x 0.0001
42 0h1C2A
Rotation count
speed unit
Load Spd
Unit
0
Rpm
0: rpm O O I -
1
mpm
6.11 User Sequence group (USS)
This group appears when APP-02 is set to 1 (Yes) or COM-95 is set to 2 (P2P Master). The parameter
cannot be changed while the user sequence is running.
SL: Sensorless vector control function (DRV-09) , I – IM Sensorless, P – PM Sensorless
*O/X: Write-enabled during operation
Code
Comm.
Address
Name LCD Display
Setting
Range
Initial
Value
Property* V/F SL Ref.
00
-
Jump code
Jump Code
1-99
31
O
O
I/P
p.52
01 0h1D01
User sequence
operation
command
User Seq Con
0
Stop
0: Stop X O I/P p.115
1
Run
2
Digital In
Run
02 0h1D02
User sequence
operation loop
time
US Loop Time
0
0.01s
1: 0.02s X O I/P
p.115
1
0.02s
2
0.05s
3
0.1s
4
0.5s
5
1s
11 0h1D0B
Output address
link1
Link UserOut1 0-0xFFFF 0 X O I/P p.115
12 0h1D0C
Output address
link2
Link UserOut2 0-0xFFFF 0 X O I/P p.115
13 0h1D0D
Output address
link3
Link UserOut3 0-0xFFFF 0 X O I/P p.115
