190
Table of Functions
6.7 Communication Function group (PARCOM)
In the following table, the data shaded in grey will be displayed when a related code has been
selected.
SL: Sensorless vector control (DRV-09) , I IM Sensorless, P PM Sensorless
*O/X: Write-enabled during operation
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property*
V/F SL Ref.
00
-
Jump Code
Jump Code
1-99
20
O
O
I/P
p.52
01 0h1701
Built-in
communication
inverter ID
Int485 St ID 1-250 1 O O I/P p.127
02
43
0h1702
Built-in
communication
protocol
Int485
Proto
0
ModBus RTU
0:
ModBus
RTU
O O I/P p.127
2 LS Inv 485
03
43
0h1703
Built-in
communication
speed
Int485
BaudR
0
1200 bps
3:
9600 bps
O O I/P p.127
1
2400 bps
2
4800 bps
3
9600 bps
4
19200 bps
5
38400 bps
6
56 Kbps
7
115 Kbps
44
04
43
0h1704
Built-in
communication
frame setting
Int485
Mode
0
D8/PN/S1
0:
D8/PN/S1
O O I/P p.127
1
D8/PN/S2
2
D8/PE/S1
3
D8/PO/S1
05
43
0h1705
Transmission
delay
after reception
Resp Delay 0-1000(ms) 5ms O O I/P p.127
06
45
0h1706
Communication
option
S/W version
FBus S/W
Ver
- 0.00 O O I/P -
07
45
0h1707
Communication
option
inverter ID
FBus ID 0-255 1 O O I/P -
08
45
0h1708
FIELD BUS
communication
speed
FBUS
BaudRate
- 12Mbps - O I/P
-
43
Will not be displayed when P2P and Multi KPD is set
44
115,200 bps
45
Displayed only when a communication option card is installed
