Table of Functions
191
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property*
V/F SL Ref.
09
45
0h1709
Communication
option LED
status
FieldBus
LED
- - O O I/P -
30 0h171E
Number of
output
parameters
ParaStatus
Num
0-8 3 O O I/P p.132
31
46
0h171F
Output
Communication
address1
Para Stauts-
1
0000-FFFF Hex 000A O O I/P p.132
32
46
0h1720
Output
Communication
address2
Para Stauts-
2
0000-FFFF Hex 000E O O I/P p.132
33
46
0h1721
Output
Communication
address3
Para Stauts-
3
0000-FFFF Hex 000F O O I/P p.132
34
46
0h1722
Output
Communication
address4
Para Stauts-
4
0000-FFFF Hex 0000 O O I/P p.132
35
46
0h1723
Output
Communication
address5
Para Stauts-
5
0000-FFFF Hex 0000 O O I/P
p.132
36
46
0h1724
Output
Communication
address6
Para Stauts-
6
0000-FFFF Hex 0000 O O I/P p.132
37
46
0h1725
Output
Communication
address7
Para Stauts-
7
0000-FFFF Hex 0000 O O I/P p.132
38
46
0h1726
Output
Communication
address8
Para Stauts-
8
0000-FFFF Hex 0000 O O I/P p.132
50 0h1732
Number of input
parameters
Para Ctrl
Num
0-8 2 O O I/P p.132
51
47
0h1733
Input
Communication
address1
Para
Control-1
0000-FFFF Hex 0005 X O I/P p.132
52
47
0h1734
Input
Communication
address2
Para
Control-2
0000-FFFF Hex 0006 X O I/P p.132
53
47
0h1735
Input
Communication
address3
Para
Control-3
0000-FFFF Hex 0000 X O I/P p.132
46
Only the range of addresses set at COM-30 is displayed.
47
Only the range of addresses set at COM-50 is displayed.
