LSIS S100 User Manual

192
Table of Functions
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property* V/F SL Ref.
54
47
0h1736
Input
Communication
address4
Para
Control-4
0000-FFFF Hex 0000 X O I/P p.132
55
47
0h1737
Input
Communication
address5
Para
Control-5
0000-FFFF Hex 0000 X O I/P p.132
56
47
0h1738
Input
Communication
address6
Para
Control-6
0000-FFFF Hex 0000 X O I/P p.132
57
47
0h1739
Input
Communication
address7
Para
Control-7
0000-FFFF Hex 0000 X O I/P p.132
58
47
0h173A
Input
Communication
address8
Para
Control-8
0000-FFFF Hex 0000 X O I/P p.132
68 0h1744
Field bus data
swap
FBus Swap
Sel
0
No
0 X O I/P -
1
Yes
70 0h1746
Communication
multi-function
input 1
Virtual DI 1 0 None 0:None O O I/P p.151
71 0h1747
Communication
multi-function
input 2
Virtual DI 2 1 Fx 0:None O O I/P p.151
72 0h1748
Communication
multi-function
input 3
Virtual DI 3 2 Rx 0:None O O I/P p.151
73 0h1749
Communication
multi-function
input 4
Virtual DI 4 3 RST 0:None O O I/P p.151
74 0h174A
Communication
multi-function
input 5
Virtual DI 5 4 External Trip 0:None O O I/P p.151
75 0h174B
Communication
multi-function
input 6
Virtual DI 6 5 BX 0:None O O I/P p.151
76 0h174C
Communication
multi-function
input 7
Virtual DI 7 6 JOG 0:None O O I/P p.151
77 0h174D
Communication
multi-function
input 8
Virtual DI 8
7
Speed-L
0:None O O I/P p.151
8
Speed-M
9
Speed-H
11
XCEL-L
12
XCEL-M
