Preparing the Installation
1 Preparing the Installation
This chapter provides details on product identification, part names, correct installation and cable
specifications. To install the inverter correctly and safely, carefully read and follow the instructions.
1.1 Product Identification
The S100 Inverter is manufactured in a range of product groups based on drive capacity and
power source specifications. Product name and specifications are detailed on the rating plate. The
illustration on the next page shows the location of the rating plate. Check the rating plate before
installing the product and make sure that the product meets your requirements. For more
detailed product specifications, refer to 9.1 Input and Output Specification on page 247
.
Check the product name, open the packaging, and then confirm that the product is free from defects.
Contact your supplier if you have any issues or questions about your product.
