LSIS S100 User Manual

145
RS-485 Communication Features
5.5 S100 Expansion Common Area Parameter
5.5.1 Monitoring Area Parameter (Read Only)
Comm. Address Parameter Scale Unit Assigned content by bit
0h0300 Inverter model - - S100: 0006h
0h0301 Inverter capacity - -
0.4 kW: 1900h, 0.75 kW: 3200h
1.1 kW: 4011h, 1.5 kW: 4015h
2.2 kW: 4022h, 3.0 kW: 4030h
3.7 kW: 4037h, 4.0 kW: 4040h
5.5 kW: 4055h, 7.5 kW: 4075h
11 kW: 40B0h, 15 kW: 40F0h
18.5 kW: 4125h, 22 kW: 4160h
30 kW: 41E0h, 37 kW: 4250h
45 kW: 42D0h, 55 kW: 4370h
75 kW: 44B0h
0h0302
Inverter input
voltage/power
(Single phase, 3-
phase)/cooling
method
- -
100 V single phase self cooling: 0120h, 200 V
3-phase forced cooling: 0231h
100 V single phase forced cooling: 0121h, 400
V single phase self cooling: 0420h
200 V single phase self cooling: 0220h, 400 V
3-phase self cooling: 0430h
200 V 3-phase self cooling: 0230h, 400 V single
phase forced cooling: 0421h
200 V single phase forced cooling: 0221h, 400
V 3-phase forced cooling: 0431h
0h0303
Inverter S/W
version
- -
(Ex) 0h0100: Version 1.00
0h0101: Version 1.01
0h0304 Reserved - - -
0h0305
Inverter operation
state
- -
B15
0: Normal state
4: Warning occurred
8: Fault occurred [operates
according to PRT- 30 (Trip Out
Mode) setting.]
B14
B13
B12
B11 -
-
B8
B7 1: Speed searching
