144
RS-485 Communication Features
Comm. Address Parameter Scale Unit R/W Assigned Content by Bit
B0
Latch Type trip
0h0010
Input terminal
information
- - R
B15-
B7
Reserved
B6
P7
B5
P6
B4
P5
B3
P4
B2
P3
B1
P2
B0
P1
0h0011
Output terminal
information
- - R
B15
Reserved
B14
Reserved
B13
Reserved
B12
Reserved
B11
Reserved
B10
Reserved
B9
Reserved
B8
Reserved
B7
Reserved
B6
Reserved
B5
Reserved
B4
Reserved
B3
Reserved
B2
Reserved
B1
MO
B0
Relay 1
0h0012
V1
0.01
%
R
V1 input voltage
0h0013
V2
0.01
%
R
V2 input voltage
0h0014
I2
0.01
%
R
I2 input current
0h0015
Motor rotation
speed
1 rpm R Displays existing motor rotation speed
0h0016
- 0h0019
Reserved - - - -
0h001A
Select Hz/rpm
-
-
R
0: Hz unit, 1: rpm unit
0h001B
Display the number
of poles for the
selected motor
- - R
Display the number of poles for the
selected motor
