RS-485 Communication Features
Comm. Address Parameter Scale Unit R/W Assigned Content by Bit
0h0008
Deceleration time
0.1
s
R/W
-
0h0009
Output current
0.1
A
R
-
0h000A
Output frequency
0.01
Hz
R
-
0h000B
Output voltage
1
V
R
-
0h000C
DC link voltage
1
V
R
-
0h000D
Output power
0.1
kW
R
-
0h000E Operation status - - R
B15
0: Remote, 1: Keypad Local
B14
1: Frequency command
source by communication
(built-in, option)
B13
1: Operation command
source by communication
(built-in, option)
B12
Reverse operation command
B11
Forward operation command
B10
Brake release signal
B9
Jog mode
B8
Drive stopped.
B7
DC Braking
B6
Speed reached
B5
Decelerating
B4
Accelerating
B3
Fault Trip - operates
according to OUT-30 setting
B2
Operating in reverse direction
B1
Operating in forward
direction
B0
Stopped
0h000F
Fault trip
information
- - R
B15
Reserved
B14
Reserved
B13
Reserved
B12
Reserved
B11
Reserved
B10
H/W-Diag
B9
Reserved
B8
Reserved
B7
Reserved
B6
Reserved
B5
Reserved
B4
Reserved
B3
Level Type trip
B2
Reserved
B1
Reserved
