LSIS S100 User Manual

Table of Functions
165
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property
*
V/F SL Ref.
78
8
0h124E
Multi-step
acceleration
time5
Acc Time-5 0.0-600.0(s) 40.0 O O I/P p.91
79
8
0h124F
Multi-step
deceleration
time5
Dec Time-5 0.0-600.0(s) 40.0 O O I/P p.91
80
8
0h1250
Multi-step
acceleration
time6
Acc Time-6 0.0-600.0(s) 30.0 O O I/P p.91
81
8
0h1251
Multi-step
deceleration
time6
Dec Time-6 0.0-600.0(s) 30.0 O O I/P p.91
82
8
0h1252
Multi-step
acceleration
time7
Acc Time-7 0.0-600.0(s) 20.0 O O I/P p.91
83
8
0h1253
Multi-step
deceleration
time7
Dec Time-7 0.0-600.0(s) 20.0 O O I/P p.91
6.3 Advanced Function group (PAR→ADV)
In the following table, the data shaded in grey will be displayed when a related code has been
selected.
SL: Sensorless vector control (DRV-09) , I – IM Sensorless, P – PM Sensorless
*O/X: Write-enabled during operation
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property* V/F SL Ref.
00
-
Jump Code
Jump Code
1-99
24
O
O
I/P
p.52
01 0h1301
Acceleration
pattern
Acc Pattern 0 Linear
0:
Linear
X O I/P p.94
02 0h1302
Deceleration
pattern
Dec Pattern 1 S-curve
X O I/P p.94
03
9
0h1303
S-curve
acceleration
start point
gradient
Acc S Start 1-100(%)
40 X O I/P p.94
9
Displayed when ADV- 01 is set to 1 (S-curve)
