Table of Functions
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property
*
V/F SL Ref.
52 0h1234
Multi-step
speed
frequency3
Step Freq-3
0.00-Maximum
frequency(Hz)
30.00 O O I/P p.79
53
7
0h1235
Multi-step
speed
frequency4
Step Freq-4
0.00-Maximum
frequency(Hz)
40.00 O O I/P p.79
54
7
0h1236
Multi-step
speed
frequency5
Step Freq-5
0.00-Maximum
frequency(Hz)
50.00 O O I/P p.79
55
7
0h1237
Multi-step
speed
frequency6
Step Freq-6
0.00-Maximum
frequency(Hz)
Maximu
m
frequen
cy
O O I/P p.79
56
7
0h1238
Multi-step
speed
frequency7
Step Freq-7
0.00-Maximum
frequency(Hz)
Maximu
m
frequen
cy
O O I/P p.79
70 0h1246
Multi-step
acceleration
time1
Acc Time-1 0.0-600.0(s)
20.0 O O I/P p.91
71 0h1247
Multi-step
deceleration
time1
Dec Time-1 0.0-600.0(s)
20.0 O O I/P p.91
72
8
0h1248
Multi-step
acceleration
time2
Acc Time-2 0.0-600.0(s)
30.0 O O I/P p.91
73
8
0h1249
Multi-step
deceleration
time2
Dec Time-2 0.0-600.0(s)
30.0 O O I/P p.91
74
8
0h124A
Multi-step
acceleration
time3
Acc Time-3 0.0-600.0(s)
40.0 O O I/P p.91
75
8
0h124B
Multi-step
deceleration
time3
Dec Time-3 0.0-600.0(s)
40.0 O O I/P p.91
76
8
0h124C
Multi-step
acceleration
time4
Acc Time-4 0.0-600.0(s)
50.0 O O I/P p.91
77
8
0h124D
Multi-step
deceleration
time4
Dec Time-4 0.0-600.0(s) 50.0 O O I/P p.91
7
Displayed when one of IN-65-71 is set to Speed–L/M/H
8
Displayed when one of IN-65-71 is set to Xcel–L/M/H
