LSIS S100 User Manual

Table of Functions
163
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property
*
V/F SL Ref.
28
5
-
D-axis
inductance
Ld (PM)
Settings vary
depending on
the motor
specifications.
0 X X P
29
5
Q-axis
inductance
Lq (PM) 0 X X P
30
5
Flux reference PM Flux Ref 0.147 X X P
31
4
Regeneration
inductance
scale
Ls Regen
Scale
70 ~ 100[%] 80 X X I -
32
5
-
Q-axis
inductance
scale
Lq(PM) Scale 50–150[%] 100 X X P
34
5
-
PM auto tuning
level
Ld,Lq Tune
Lev
20.0–50.0[%] 33.3 X X P
35
5
-
PM auto tuning
frequency
Ld,Lq Tune Hz 80.0–150.0[%]
100.0 X X P
41
6
0h1229
User
frequency1
User Freq 1
0.00-Maximum
frequency(Hz)
15.00 X O X p.99
42
6
0h122A
User voltage1 User Volt 1 0-100(%)
25 X O X p.99
43
6
0h122B
User
frequency2
User Freq 2
0.00-0.00-
Maximum
frequency(Hz)
30.00 X O X p.99
44
6
0h122C
User voltage2 User Volt 2 0-100(%)
50 X O X p.99
45
6
0h122D
User
frequency3
User Freq 3
0.00-Maximum
frequency(Hz)
45.00 X O X p.99
46
6
0h122E
User voltage3 User Volt 3 0-100(%)
75 X O X p.99
47
6
0h122F
User
frequency4
User Freq 4
0.00-Maximum
frequency(Hz)
Maximu
m
frequen
cy
X O X p.99
48
6
0h1230
User voltage4 User Volt 4 0-100(%)
100 X O X p.99
50 0h1232
Multi-step
speed
frequency1
Step Freq-1
0.00-Maximum
frequency(Hz)
10.00 O O I/P p.79
51 0h1233
Multi-step
speed
frequency2
Step Freq-2
0.00-Maximum
frequency(Hz)
20.00 O O I/P p.79
5
Displayed when DRV-09 (Control Mode) is set to 6 (PM Sensorless).
6
Displayed when either BAS-07 or M2-25 is set to 2 (User V/F)
