Table of Functions
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property
*
V/F SL Ref.
12 0h120C
Rated slip
speed
Rated Slip 0-3000(Rpm)
motor
setting
X O I -
13 0h120D
Motor rated
current
Rated Curr 1.0-1000.0(A)
X O I/P -
14 0h120E
Motor noload
current
Noload Curr 0.0-1000.0(A)
X O I -
15 0h120F
Motor rated
voltage
Rated Volt 170-480(V)
0 X O I/P p.102
16 0h1210
Motor
efficiency
Efficiency 64-100(%)
Depend
ent on
motor
setting
X O I/P -
17 0h1211
Load inertia
rate
Inertia Rate 0-8
X O I/P -
18 0h1212
Trim power
display
Trim Power % 70-130(%)
O O I/P -
19 0h1213
Input power
voltage
AC Input Volt 170-480 V
220/380
V
O O I/P -
20 -
Auto Tuning
Auto
Tuning
0
None
0:None X X I/P -
1
All (Rotation
type)
2
ALL (Static
type)
3
Rs+Lsigma
(Rotation
type)
6
Tr (Static
type)
7 All PM
21
-
Stator resistor
Rs
Dependent on
motor setting
Depend
ent on
motor
setting
X
X
I/P
-
22 -
Leakage
inductance
Lsigma
X X I -
23 -
Stator
inductance
Ls
X X I -
24
4
-
Rotor time
constant
Tr 25-5000(ms)
- X X I -
25
4
-
Stator
inductance
scale
Ls Scale 50-150(%)
100 X X I -
26
4
-
Rotor time
constant scale
Tr Scale 50-150(%) 100 X X I -
4
Displayed when DRV-09 is set to 4(IM Sensorless)
