LSIS S100 User Manual

Table of Functions
161
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property
*
V/F SL Ref.
5
Mx[G*2(A-
50%)
6
M/[G*2(A-
50%)]
7
M+M*G*2(A-
50%)
03
3
0h1203
Auxiliary
command gain
Aux Ref Gain -200.0-200.0(%)
100.0 O O I/P -
04 0h1204
2nd command
source
Cmd 2nd Src
0
Keypad
1:
Fx/Rx-1
X O I/P p.111
1
Fx/Rx-1
2
Fx/Rx-2
3
Int 485
4
FieldBus
05 0h1205
2nd frequency
source
Freq 2nd Src
0
Keypad-1
0:
Keypad-
1
O O I/P p.111
1
Keypad-2
2
V1
4
V2
5
I2
6
Int 485
8
FieldBus
9
UserSeqLink
12
Pulse
06 0h1206
2nd Torque
command
source
Trq 2
nd
Src
0
Keypad-1
0:
Keypad-
1
O X I
1
Keypad-2
2
V1
4
V2
5
I2
6
Int 485
8
FieldBus
9
UserSeqLink
12
Pulse
07 0h1207
V/F pattern
options
V/F Pattern
0
Linear
0:
Linear
X O X p.97
1
Square
2
User V/F
3
Square 2
08 0h1208
Acc/dec
standard
frequency
Ramp T Mode
0
Max Freq
0:
Max
Freq
X O I/P p.89
1 Delta Freq
09 0h1209
Time scale
settings
Time Scale
0
0.01 sec
1:0.1 sec X O I/P p.89
1
0.1 sec
2
1 sec
10 0h120A
Input power
frequency
60/50 Hz Sel
0
60 Hz
0:60 Hz X O I/P -
1
50 Hz
11 0h120B
Number of
motor poles
Pole Number 2-48
Depend
ent on
X O I/P -
