LSIS SV-iS7 series User Manual

Chapter 8 Table of Functions
G
8-12
No.
Comm.
No.
Function
Display
Name Setting Range Initial Value
Shift in
Operation
Control Mod
e
V/F
SL
VC
SLT
VC
T
Gain1 speed control
period
proportional
gain1
motor
capacity
22 0h1416
ASR-SL I
Gain1
sensorless1, 2
speed control
period integral
calculu
s
gain 1
10 ~ 9999 [ms]
O X O X X X
23
Note 16)
0h1417
ASR-SL P
Gain2
Sensorles
s
2
speed control
period
proportional gain
2
1 ~ 1000 [%]
Depends on
motor
capacity
O X X X X X
24 0h1418
ASR-SL I
Gain2
Sensorles
s
2
speed control
period integral
calculu
s
gain 2
O X X X X X
26 0h141A
Observer
Gain1
Sensorles
s
2
measurer gain 1
0 ~ 30000 10500 O X X X X X
27 0h141B
Observer
Gain2
Sensorles
s
2
measurer gain 2
1 ~ 1000 [%] 100.0 O X X X X X
28 0h141C
Observer
Gain3
Sensorles
s
2
measurer gain 3
0 ~ 30000 13000 O X X X X X
29 0h141D
S-Est P
Gain1
Sensorles
s
2
speed estimator
proportional gain
1
0 ~ 30000
Depends on
motor
capacity
O X X X X X
30 0h141E S-Est I Gain1
S
ensorless 2 speed
estimator integral
calculus gain1
O X X X X X
31 0h141F
S-Est P
Gain2
Sensorless2
speed estimator
proportional
gain2
1 ~ 1000 [%]
Depends on
motor
capacity
O X X X X X
32 0h1420
S-Est I
Gain2
Sensorless2
speed estimator
integral calculus
gain2
O X X X X X
34 0h1422
SL2 OVM
Perc
Sensorless2
overvoltage
modulation
range
adjustmen
t
100 ~ 180 [%] 120 X X O X X X
4
5
Note17)
0h142D PG P Gain
PG operation
proportional gain
0 ~ 9999 3000 O O X X X X
