LSIS SV-iS7 series User Manual

Chapter 8 Table of Functions
G
8-28
No. Comm. No. Function Display Name Setting Range
Initial
Value
Shift in
Operation
Control Mode
V/F
SL
VC
SLT
VCT
21 0h1815
PID
F/B Source
PID Feedback selection
0 V1
0 : V1 X O O O X X
1 I1
2 V2
3 I2
4 Int 48
5
5 Encode
r
6 FieldBu
s
7 PL
C
8 Synchr
o
9
Binary
Type
2
2
0h1816 PID P-Gain PID proportional gain 0
~
1000 [%] 50.0
O
O O O X X
23 0h1817 PID I-Time PID integral calculus time 0
~
200.0 [s] 10.0
O
O O O X X
24 0h181
8
PID D-Time PID differential time 0
~
1000 [ms] 0
O
O O O X X
2
5
0h181
9
PID F-Gain PID Feed forward gain 0
~
1000.0 [%] 0.0
O
O O O X X
26 0h181
A
P Gain Scale Proportional gain scale 0
~
100.0 [%] 100.0 X O O O X X
27 0h181B PID Out LP
F
PID output filter 0~10000 [ms] 0
O
O O O X X
29 0h181D PID Limit Hi PID upper limit frequency
PID lower limit
frequency [Hz] ~
300 [Hz]
60.00 O O O O X X
30 0h181E PID Limit Lo PID lower limit frequency
-300 ~ PID upper
limit frequency
[Hz]
-60 O O O O X X
31 0h181F PID Out Inv PID output reversal
0 N
o
0 : No X O O O X X
1 Ye
s
32 0h1820
PID Out
Scale
PID output scale 0.1 ~ 1000 [%] 100.0 X O O O X X
34 0h1822 Pre-PID Freq
PID control period
movement frequency
0
~
max.
freq.[Hz]
0.00 X O O O X X
35 0h1823 Pre-PID Exit
PID control period
movement level
0 ~ 100 [%] 0.0 X O O O X X
36 0h1824
Pre-PID
Delay
PID control period
movement delay time
0 ~ 9999 [s]
600 O O O O X X
37 0h1825 PID Sleep DT PID sleep mode delay time 60.0 O O O O X X
38 0h1826
PID Sleep
Freq
PID Sleep mode frequency
0
~
max.
freq.[Hz]
0.00 O O O O X X
39 0h1827
PID WakeUp
Lev
PID Wake up level 0 ~ 100 [%] 35 O O O O X X
40 0h1828
PID WakeUp
Mod
PID Wake up mode setting
0
Below
Level
0:
Below
Level
O O O O X X
1
A
bove
Level
