LSIS SV-iS7 series User Manual

Chapter 8 Table of Functions
G
8-38
No. Comm. No.
Function
Display
Name Setting Range
Initial
Value
Shift in
Operation
Control Mod
e
V/F
SL
VC
SLT
VCT
52 0h1B34 Stall Level 1 stall level 1 30 ~ 250 [%] 180 X O O X O X
53 0h1B35 Stall Freq 2 stall frequency 2
stall frequency 1
~ stall frequency 2[Hz]
60.00 O O
OXOX
54 0h1B36 Stall Level 2 stall level 2 30 ~ 250 [%] 180 X O O X O X
55 0h1B37 Stall Freq 3 stall frequency 3
stall frequency 2
~ stall frequency 4[Hz]
60.00 O O O X O X
56 0h1B38 Stall Level 3 stall level 3 30 ~ 250 [%] 180 X O O X O X
57 0h1B39 Stall Freq 4 stall frequency 4
stall frequency 3
~ max. freq.[Hz]
60.00 O
OOXOX
58 0h1B3A Stall Level 4 stall level 4 30 ~ 250 [%] 180 X O O X O X
66 0h1B42 DB Warn %ED
DB resistance warning
level
0 ~ 30 [%] 0 O OOOOO
70 0h1B46
Over SPD
Freq
overspeed judgment
frequency
20 ~ 130 [%] 120.0 O X X O X O
72 0h1B48
Over SPD
Time
overspeed judgment time
0.01 ~ 10.00 [s] 0.01 O X X O X O
73 0h1B49
Speed Dev
Trip
speed error failure
0 No
0 : No O X X O X X
1 Yes
74 0h1B4A
Speed Dev
Band
speed error width
2 ~ max.
freq.[Hz]
20.00 O X X O X X
75 0h1B4B
Speed Dev
Time
speed error judgment
time
0.1 ~ 1000.0 [s] 1.0 O X X O X X
77 0h1B4D
Enc Wire
Check
Encoder option
connection check
0 No
0 : No O X X O X O
1 Yes
78 0h1B4E
Enc Check
Time
Encoder connection
check time
0.1 ~ 1000.0 [s] 1.0 O X X O X O
79 0h1B4F FAN Trip Mode
cooling fan failure
selection
0 Trip
0 : Trip O O O O O O
1 Warning
80 0h1B50 Opt Trip Mode
movement selection in
case of option trip
0 None
1 :
Free-
Run
OOOOOO
1 Free-Run
2 Dec
81 0h1B51 LVT Delay
low voltage failure
judgment delay time
0 ~ 60.0 [s] 0.0 X OOOOO
_YG
WXi\YG
s}YGlG
jG 

T
G G
G
0 No
Wau G vG vG v v v
1 Yes
* The grey code refers to hidden code, emerging only in case of setting of the code.
Note 38)
PRT-10 code is displayed only when PRT-09(Retry Number) is set the value more than “0”.
Note 39)
PRT-13~15 codes are displayed only when PRT-12(Lost Cmd Mode) is not set as “NONE”.
