LSIS SV-iS7 series User Manual

Chapter 8 Table of Functions
G
8-44
8.1.16 User/Macro mode – Traverse operation function group (
Î
MC2)
G
No. Function Display Name Setting Range Initial Value
00 Jump Code jump code 0 ~ 99 1
01 Acc Time accelerating time
0 ~ 600 [s]
Below 75k
W
20
A
bove 90k
W
60
02 Dec Time decelerating time
Below 75k
W
30
A
bove 90k
W
90
03 Cmd Source operating command method 0 ~ 5 1 : Fx/Rx-1
04 Freq Ref Src frequency setting method 0 ~ 9 0 : Keypad-1
05 Control Mode control mode 0 ~ 5 0 : V/F
06 Trv Apmlit % traverse operating range 0 ~ 20 [%] 0.0
07 Trv Scramb % traverse scramble magnitude 0 ~ 50 [%] 0.0
08 Trv Acc Time traverse accelerating time
0.1 ~ 600 [s]
2.0
09 Trv Dec Time traverse decelerating time 3.0
10 Trv Offset Hi traverse offset upper limit
0 ~ 20 [%]
0.0
11 Trv Offset lo traverse offset lower limit 0.0
12 P1 Define P1terminal function setting
0 ~ 48
0 : FX
13 P2 Define P2terminal function setting 1 : RX
14 P3 Define P3terminal function setting 5 : BX
15 P4 Define P4terminal function setting 27 : Trv
16 P5 Define P5terminal function setting 28 : Trv
