Lucent Technologies FiberReach DDM-2000 - Page 141

363-206-305
Applications
Issue 3 June 2000
2-55
Figure 2-41. DDM-2000 FiberReach Multiplexer Business Narrowband Application
. . .
DDM-2000
FiberReach
. . .
DDM-2000
FiberReach
DS1
WIRE CENTER
OC-1
DDM-2000
OC-3/OC-12
OC-3/OC-12
DDM-2000
OC-3/OC-12
5ESS
DS1
DS0, DS1,
T1
DS0, DS1,
T1
TR-08/
303
tpa 843647/01
R
SLC
-2000
Wideband
Narrowband
Wideband
Narrowband
DS1/
EC1
DACS IV-
2000
DACS II
R
RT Access
System
DDM-2000
OC-3
Switch
