363-206-305 Detailed Level Procedure:
DLP-508
Issue 3, June 2000 Page 3 of 4
DDM-2000 F
IBER
R
EACH
W
IDEBAND
S
HELF
6.
NOTE:
One protection DS1/DS1PM circuit pack may be installed for each
service DS1/DS1PM circuit pack installed, if the shelf is equipped for 1X1
protection mode. One protection DS1/DS1PM circuit pack may be
installed to protect all service DS1/DS1PM circuit packs installed, if the
shelf is equipped for 1X7 protection mode. The SYSCTL automatically
provisions the protection DS1/DS1PM circuit pack to match the line code
setting (B8ZS or AMI) of any service DS1/DS1PM circuit pack that it
protects.
Is protection DS1 circuit pack(s) being installed?
If YES, continue with Step 7.
If NO, STOP. YOU HAVE COMPLETED THIS PROCEDURE.
7. Refer to Figure 1 and Table A and set LBO option switches on protection
DS1/DS1PM circuit pack(s).
8. Is shelf equipped for 1X1 or 1X7 protection mode.
If 1X1, continue with Step 9.
If 1X7, proceed to Step 11.
9. Seat protection DS1/DS1PM circuit pack into LS-[A-2, B-2, C-2, or D-2] slot
immediately above the service low-speed group being equipped.
10. STOP. YOU HAVE COMPLETED THIS PROCEDURE.
11. Seat protection DS1/DS1PM circuit pack into slot LS-[D-2].
12. Install 177A Apparatus Blanks into all unequipped service and protection DS1
slots, if required.
13. STOP. YOU HAVE COMPLETED THIS PROCEDURE.
