DLP-514
: Detailed Level Procedure 363-206-305
Page 14 of 22 Issue 3, June 2000
DDM-2000 F
IBER
R
EACH
W
IDEBAND
S
HELF
Table J – DDM-2000 FiberReach Operating at OC-12 Rate to OC-12 Shelf or FT-2000
OC-12 LS INTFC Measured Optical Power and Required LBO
Transmitter
Receiver
T939A OC12
(FT-2000)
29G-U/29H-U OLIU
(FiberReach Shelf)
Received
Power(dBm)
LBO
(dB)
Received
Power(dBm)
LBO
(dB)
T939A OC12
(FT-2000)
2.0 to 1.0 15
1.0 to –4.0 10
–4.0 to –9.0 5
–9.0 to –31.0 0
29G-U/29H-U OLIU
(FiberReach Shelf)
2.0 to 1.0 15 2.0 to 1.0 15
1.0 to –4.0 10 1.0 to –4.0 10
–4.0 to –9.0 5 –4.0 to –9.0 5
–9.0 to –31.0 0 –9.0 to –31.0 0
Notes:
1. Measured power is defined to be the measured power of the light emitted from receive fiber
connector at OLIU.
2. The minimum measured received power allows for optical path penalty and unallocated margin.
Connector loss is not allotted for; it should already be accounted for in the optical power
measurement.
3. The margin for falling within the max rx power is 1.0 dB.
