363-206-305 Detailed Level Procedure:
DLP-514
Issue 3, June 2000 Page 15 of 22
DDM-2000 F
IBER
R
EACH
W
IDEBAND
S
HELF
Table K – DDM-2000 FiberReach Operating at OC-12 Rate to OC-12 Shelf
Measured Optical Power and Required LBO
Transmitter
Receiver
29G-U/29H-U OLIU
(FiberReach Shelf
With OC-12 Optics)
23G/23G-U OLIU
(OC-12 Shelf)
23H/23H-U OLIU
(OC-12 Shelf)
Received
Power(dBm)
LBO
(dB)
Received
Power(dBm)
LBO
(dB)
Received
Power(dBm)
LBO
(dB)
29G-U/29H-U OLIU
(FiberReach Shelf
With OC-12 Optics)
2.0 to –3.0 20
2.0 to 1.0 15 2.0 to 1.0 15 –3.0 to –8.0 15
1.0 to –4.0 10 1.0 to –4.0 10 –8.0 to –13.0 10
–4.0 to –9.0 5 –4.0 to –9.0 5 –13.0 to –18.0 5
–9.0 to –31.0 0 –9.0 to –31.0 0 –18.0 to –34.0 0
23G/23G-U OLIU
(OC-12 Shel
f)
2.0 to 1.0 15
1.0 to –4.0 10
–4.0 to –9.0 5
–9.0 to –31.0 0
23H/23H-U OLIU
(OC-12 Shelf)
2.0 to 1.0 15
1.0 to –4.0 10
–4.0 to –9.0 5
–9.0 to –31.0 0
Notes:
1. Measured power is defined to be the measured power of the light emitted from receive fiber connector
at OLIU.
2. The minimum measured received power allows for optical path penalty and unallocated margin.
Connector loss is not allotted for; it should already be accounted for in the optical power measurement.
3. The margin for falling within the max rx power is 1.0 dB.
