115
SC100/200 Series Users Manual EM-6337-B Rev.15
LOOP 2
REGISTER PARAMETER R/W DESCRIPTION
40101 PV R Process value (-15.00 to 115.00%, Data range -1500 to 11500)
40102 SP R/W Set point (-15.00 to 115.00%, Data range -1500 to 11500)
(±32.000, Data range ±32000 for Ratio Setting)
40103 MV R/W Manipulated value (±115.00%, Data range ±11500)
40104 PB R/W Proportional band (0 to 1000%, Data range 0 to 1000)
40105 TI R/W Integral time (0.00 to 100.00 minutes, Data range 0 to 10000)
40106 TD R/W Derivative time (0.00 to 10.00 minutes, Data range 0 to 1000)
40107 PH R/W PV high alarm setpoint (-15.00 to 115.00%, Data range -1500 to 11500)
40108 PL R/W PV low alarm setpoint (-15.00 to 115.00%, Data range -1500 to 11500)
40109 DL R/W Deviation alarm setpoint (0.00 to 115.00%, Data range 0 to 11500)
40110 MH R/W MV high limit (±115.00%, Data range ±11500)
40111 ML R/W MV low limit (±115.00%, Data range ±11500)
40112 RH R/W Range high limit (±32000, Data range ±32000)
40113 RL R/W Range low limit (±32000, Data range ±32000)
40114 DP R/W Decimal point position (0 to 5, Data range 0 to 5)
101 C/L R/W Cascade / Local (0: Local, 1: Cascade)
102 A/M R/W Auto / Manual (0: Manual, 1: Auto)
103 PHA R PV high alarm (0: Normal, 1: Alarm)
104 PLA R PV low alarm (0: Normal, 1: Alarm)
105 ---- ---- Reserved (DO NOT WRITE)
106 MD R/W MV reverse indication (0: Direct, 1: Reverse)
COMMUNICATION TERMINAL (ANALOG)
REGISTER PARAMETER R/W DESCRIPTION
40301 Gr11 A1 R/(W) Group 11, Analog terminal 1 (-15.00 to 115.00%, Data range -1500 to 11500)
40302 Gr11 A2 R/(W) Group 11, Analog terminal 2 (-15.00 to 115.00%, Data range -1500 to 11500)
: : : :
40331 Gr26 A1 R/(W) Group 26, Analog terminal 1 (-15.00 to 115.00%, Data range -1500 to 11500)
40332 Gr26 A2 R/(W) Group 26, Analog terminal 2 (-15.00 to 115.00%, Data range -1500 to 11500)
Read only for AO Send Terminal.
Read/Write for AI Receive Terminal (Set ITEM 11 to FE)
COMMUNICATION TERMINAL (DISCRETE)
REGISTER PARAMETER R/W DESCRIPTION
301 Gr11 D1 R/(W) Group 11, Discrete terminal 1
: : : :
332 Gr11 D32 R/(W) Group 11, Discrete terminal 32
: : : :
781 Gr26 D1 R/(W) Group 26, Discrete terminal 1
: : : :
812 Gr26 D32 R/(W) Group 26, Discrete terminal 32
Read only for DO Send Terminal.
Read/Write for DI Receive Terminal (Set ITEM 11 to FE)
Either of AO Send, AI Receive, DO Send, DI Receive Terminal can be assigned to each Group.
