9
SC100/200 Series Users Manual EM-6337-B Rev.15
Minimizing noise interference to analog signal cables
• Noise entering through the analog signal cables may cause irregular measurement values, degradation of overall accuracy,
and malfunction of the product. We recommend that you would conduct wiring to the unit with the following points of cau-
tion.
• Do not install cables close to noise sources (high frequency line, etc.).
• Do not bind the analog I/O cables together with those in which noises are present. Do not install them in the same duct.
DO NOT apply overrange input
• Do not apply voltages exceeding ±15 V across the voltage input terminals to prevent damage.
• Do not apply currents exceeding ±30 mA to the current input terminals to prevent damage.
Connector adaptor
• Connector adaptor is included in the product package when “stereo jack” is specied for “congurator interface” when order-
ing the product.
• Connect the adaptor to the stereo jack end of the congurator cable (model: COP-US).
Stereo jack port
• Stereo jack port is covered with a cap to prevent water/moisture in it. Take precaution so that water/moisture does not enter
in it when using the congurator cable or when putting the cap on and off.
• Do not leave water/moisture inside the stereo jack port. If water/moisture is present, be sure to blow it off before using it.
• For using the port, remove the cap and insert the congurator cable connected with the adaptor.
• Be sure to put back the cap onto the port after removing the cable.
And ....
• We recommend use of an UPS to supply power backups.
• The unit is designed to function as soon as power is supplied, however, a warm up for 10 minutes is required for satisfying
complete performance described in the data sheet.
• Refer to 4. INSTALLATION regarding the points of caution to be considered when installing the Controller.
■ APPLICABLE FIRMWARE VERSION
This Users Manual conforms to SC_LCD rmware version 1.50 or later. In this manual descriptions given with the following
symbols are applied only to the rmware versions.
SYMBOL APPLICABLE FIRMWARE VERSION
1.50
SC_LCD rmware version 1.50 or later
To Next Page
