3.14 Upper Cross Auger
The upper cross auger (UCA) (A) improves delivery of very bulky crops across the header.

$
Figure 3.57: Upper Cross Auger
The UCA is available as an optional kit. For more information,
refer to 6.4.3 Upper Cross Auger, page 253.
NOTE:
Optional wide draper deflectors are NOT compatible with
the UCA.
