6.2 Cutterbar Kits
The cutterbar is located on the front of the header. It supports the knife and guards which is used to cut the crop.
6.2.1 Cutterbar Wearplate
Cutterbar wearplates are recommended for cutting on the ground when the soil is adhering to the steel.
Figure 6.7: Cutterbar Wearplates
Order one of the following bundles based on header size:
• 4.6 m (15 ft.) – MD #B4864
• 6.1 m (20 ft.) – MD #B4865
• 7.6 m (25 ft.) – MD #B4838
6.2.2 Knife Cutout Cover
Figure 6.8: Knife Cutout Cover
Knife cutout covers attach to the endsheets and prevent cut
crop, particularly severely lodged crop, from passing through
the knifehead opening and accumulating in the knife drive box
and endsheet.
Order the following kits according to your guard type:
• Regular Guards – MD #220101
• Stub Guards – MD #220103
